Key features and benefits

Triple the speed, one-third the space – industry-leading performance with a reduced footprint. Unparalleled cutting precision – 1 khz scanning technology and an ultra-thin 0.7mm blade for minimal product impact. High-speed processing – up to 3,200 cuts per minute and belt speeds of 1,200mm/sec ensure rapid production. Hybrid flexibility – can integrate with existing portioning equipment to enhance efficiency without full replacement. Eco-friendly design – air-cooled motor reduces water consumption, supporting sustainability efforts.

Proteins and portions

Versatile application – suitable for poultry, fish, meat and other cubed food items.

Technical specifications

Max cutting speed: up to 4,400 cuts per minuteBelt speed: 1,200mm per secondScanning technology: 1 khz high-frequency camera systemBlade thickness: 0.7mm ultra-thin blade for enhanced accuracy and reduced product impactMachine configuration: integrates the bc225 (Leader) and BC100 (Follower) cutters in a synchronized system Capacity (Cube processing mode based on 70g strips on average):Leader unit: 300 strips per minuteFollower unit: 1200mm per second, cutting 5 strips per secondEstimated total capacity: 1260 kg/hour with optimal conditions

Turnkey line

Cube Master Line

Designed for precision portion cutting of fish, poultry and meat with exceptional efficiency and reliability.

Triple the speed, one-third the space
Full cube cutting production line
Maximizes yield and quality

Specifications

Record-breaking performance metrics

Cutting speed

High-speed processing of up to 4,400 cuts per minute

Belt speed

An unprecedented 1,200 mm per second

Advanced camera technology

1 khz scanning for next-level precision

More cuts, less space, maximum efficiency

The cube master line integrates the BC 225 and BC100 cutters into a synchronized system, achieving three times the production capacity while using only one-third of the space of conventional lines. This cutting-edge solution provides high output, precision cutting and integration flexibility, making it a cost-effective and space-saving investment for modern food processing facilities.

View the Cube Master Line brochure - PDF

BC Cube Master Line

Watch video

Robert Dubravac

Head of R&D at Borncut

“The combination of speed, the new high-frequency scanning camera, and ultra-thin blade design allow us to cut at extreme speeds with higher accuracy than ever before. Nobody else in the market is using a 1 kHz scanning system. Competitors are at 400 Hz or lower, which means we are leagues ahead in precision.”

1 khz scanning technology

Precision is key when producing high-quality cubes and borncut has introduced 1 khz scanning technology—a first in the industry. Competitors operate at 400 hz or lower, making the cube master technology a major leap forward in accuracy. The newly designed 0.7mm ultra-thin blade ensures minimal impact on the product, preserving its structure and quality throughout the cutting process.

Unparalleled precision and consistency

The BC100 is specifically designed for smaller products, featuring a narrower 100mm belt width, which allows for reduced blade size and thickness. While conventional blades range from 1.5 to 2mm, the bc100 utilizes an ultra-thin 0.7mm blade. This ensures less impact on the product and provides even greater accuracy. Additionally, the machine is equipped with an air-cooled motor, eliminating the need for extensive water cooling, making it more sustainable and cost-efficient.

A cost-effective solution with hybrid flexibility

Investing in a new machine doesn’t mean processors need to start from scratch. The cube master line can integrate with existing equipment, allowing you to upgrade your processing without a full system replacement. The machine was designed as a flexible solution. By combining the BC100 with existing portion cutters, users can increase speed and efficiency without making a massive upfront investment.

Centralized control, single interface

What sets Borncut's lines apart is centralized control. With this solution, everything—grading, portioning, weighing—can be managed from a single interface, eliminating the need for multiple software systems. This reduces complexity, minimizes setup time and enhances operational efficiency.

Borncut Cube Master Line for fish, poultry and meat

Triple the speed, one-third the space – industry-leading performance with a reduced footprint.

Unparalleled cutting precision – 1 khz scanning technology and an ultra-thin 0.7mm blade for minimal product impact.

High-speed processing – up to 3,200 cuts per minute and belt speeds of 1,200mm/sec ensure rapid production.

Hybrid flexibility – can integrate with existing portioning equipment to enhance efficiency without full replacement.

Eco-friendly design – air-cooled motor reduces water consumption, supporting sustainability efforts.
Max cutting speed: up to 4,400 cuts per minute

Belt speed: 1,200mm per second
Scanning technology: 1 khz high-frequency camera system

Blade thickness: 0.7mm ultra-thin blade for enhanced accuracy and reduced product impact

Machine configuration: integrates the bc225 (Leader) and BC100 (Follower) cutters in a synchronized system

Capacity (Cube processing mode based on 70g strips on average):

Leader unit: 300 strips per minute
Follower unit: 1200mm per second, cutting 5 strips per second
Estimated total capacity: 1260 kg/hour with optimal conditions

Dual lane Cube Master Line

Different configurations are available to accommodate various processing needs, from single to dual lanes as well as integration with existing processing systems.
